Year:	2004
Manufacturer:	Georgie Boy
Model:	BELLAGIO
RV Type:	Class A
Fuel:	Diesel
Condition:	Used
Price Range:	$150,000 - $230,000

Description

From its gorgeous full body paint exterior to its European-style interior, the all-new Bellagio has the look and feel you'd expect of a luxury diesel motor coach at a highly affordable Georgie Boy price. A new name. A new look. And a new style. Experience it for yourself and discover why Bellagio is, indeed, beyond compare.

Features

EXTERIOR

» Standard

Freightliner Chassis
Mud Flaps (Front & Rear)
Trailer Hitch
Automatic Hydraulic Leveling Jacks

» W/touch Pad

Trunk Lights w/Illuminated Switch
Patio Light with Touch Pad by Entry Door
Deluxe Exterior Grab Handle at Entry Door (Except CSA)
Electric Entry Step
Auxiliary Battery System - Three Deep Cycle (12 Volt)
Battery Disconnect System
Detachable Electrical Supply Cord 50 Amp.
2000 Watt Inverter
Single Water Fill System w/Change-Over Valves
Pneumatic Water Line - Winterizing Fitting
Exterior Shower w/Hot & Cold Water
Enclosed and Heated Holding Tank

» Compartment

Awning Rails w /Gutter
Dead Bolt Lock at Entry Door
20' Sewer Hose
Gas Struts on Exterior Doors
Deluxe Fiberglass Sidewalls
Slide Room Awnings
Automotive Underbody Undercoating
Full - Body Painted Graphics
Dual Fuel Fill
Stainless Steel Wheel Simulators

» Options

Thermo Pane Windows
Main Awning

INTERIOR

» Standard

Handrail at Entry Door
Halogen Accent Lighting Kitchen

» And Living Room

Composite Countertops
Composite Sink and Range Covers
Slide-Out Pantry

» (except W/side By Side Refer)

Ceramic Tile Floor Kitchen and Bath
Free Standing Dinette w/Two (2) Free Standing Chairs and Two (2) Extra Folding Chairs
Euro Recliner w/Ottoman - Soft Touch (3750 DS)
Day/Night Shades in Living Room and Bedroom
Upgrade Mattress
Bedspread

» Options

Area Rugs - Kitchen & Bath
Booth Dinette w/Drawers
Velvet Cherry Hardwood Cabinetry
Maple Hardwood Cabinetry
Walnut Hardwood Cabinetry
Soft Touch Versaflex Sofa

	3750 DS	3900 DS	3925 DS
CHASSIS MODEL
Freightliner	XC	XC	XC
Standard Engine Size (HP...	330	330	330
Wheel Base	228"	242"	242"
Tire size	235/80R 22.5	235/80R 22.5	235/80R 22.5
GVWR (pounds)	26,850	26,850	26,850
UVW (pounds)	23,042	TBD	TBD
GAWR Front (pounds)	9,350	9,350	9,350
GAWR Rear (pounds)	17,500	17,500	17,500
GCWR (pounds)	36,850	36,850	36,850
Exterior Length	38'	39' 2"	39' 2"
Exterior Clearance Heigh...	12' 1"	12' 1"	12' 1"
Exterior Width	8'6"	8'6"	8'6"
Interior Width	96"	96"	96"
Interior Height	6' 7"	6' 7"	6' 7"
Sleeping Capacity	5	7	5
Fuel Capacity (gal.)	90	90	90
Fresh Water Capacity (ga...	82	82	82
Waste Water Capacity (ga...	46	46	46
Grey Water Capacity (gal...	46	46	46
Water Heater Capacity	10	10	10
LP Gas Capacity (lb.)	170	170	170
Furnace Rating (x 1000) ...	40	40	40
Awning Size	18'	19'	19'

GVWR(Gross Vehicle Weight Rating): The maximum permissible weight of the unit, including the UVW plus all fluids, cargo, optional equipment and accessories. For safety and product performance, do not exceed GVWR.
UVW: Means the weight of a motor home as manufactured at the factory with fuel, engine oil and coolants. The above UVW's represent a motor home with typical options. UVW will vary significantly based on option selection.
GAWR (Gross Axle Weight Rating): The total weight each front/rear axle, suspension and tire system is designed to carry. When loading the unit, care should be taken to balance cargo weight in consideration of the GAWRs.
GCWR (Gross Combined Weight Rating): The maximum total weight of the loaded unit, plus a tow vehicle. This includes the weight of both the unit and tow vehicle, fuel for each, all other fluids, cargo, occupants, optional equipment and accessories.
* Includes clearance for air conditioner & satellite dish
