2007 Fleetwood Bounder Diesel Specs, Towing Weight, Floorplan + Features
Photo Tour
|
RV Must-Have! Never Run Out of Power Again!
|
| Year: | 2007 |
|---|---|
| Manufacturer: | Fleetwood |
| Model: | Bounder Diesel |
| RV Type: | Class A |
| Fuel: | Diesel |
| Condition: | New |
| Price Range: | $174,000 - $270,000 |
Description
Bounder is one of America's favorite RV brands. Bounder Diesel adds power and value to the mix - but it's still every bit a Bounder! Everywhere you look, from the full-body paint, to the vast storage capacity, to the fully equipped galley, you'll find thoughtful details that make Bounder Diesel such a great value. The massive 860 ft/lb of torque generated by the mighty Caterpillar® C7 diesel smoothly powers Bounder Diesel over the steepest pass and makes towing a breeze. Based on solid steel ten inch I-beams, Bounder Diesel is more stable, offers more storage, and can withstand the tow load of most vehicles. Packed with deluxe features and built to last, Bounder Diesel just may give you the biggest bang for your buck in Class A Diesel.
Features
INTERIOR
- 84" Interior Ceiling Height
- Auto A/C Heater Combo
- Cabinet Toe Kicks
- Driver/Front Passenger Ultraleather™ Captain's Chairs w/Reclining Back/Slide Controls w/Power Driver Seat
- Dual Roof-Mounted A/C High Efficiency w/Solar Panel & Chill Grille on Front A/C
- Soft-Surface Automotive Dash w/Snack Tray & Convenient Service Door
- Solid Surface Countertop, Sink & Range Covers, Mirror Backsplash in Galley
- Under Galley Shelving & Wastebasket
- Ventilated Rear Wardrobe w/Cedar Lining, Carpeted Floor & Wire Organizer
- Whole Coach Water Filtration System
EXTERIOR
- 2000 Watt Inverter w/Remote
- 300-HP Caterpillar™ Engine w/Rear-Mounted Radiator
- 4-point Automatic Electric Levelers
- Choice of Four Colorway Graphics
- Dual Fuel Fill (One on Each Side)
- Dual Pane Windows w/Screens
- Freightliner™ Chassis
- Full Body Paint
- Insulated Aluminum Luggage Doors w/Single Paddle Metal Latches & Stainless Steel Hinges
- Patio & Entry Door Awning
- Power Entry Step
- Radius Entry Door w/Deadbolt Latch (Keyless-Entry Ready)
- Royal Tuff-Ply Radius Roof w/Ducted A/C
FLEETWOOD ADVANTAGES
- Complete TuffPEX™ Plumbing System
- Energy Management System (EMS) w/Soft Start
- Power Platform Construction (Fleetwood Exclusive)
- Vacu-Bond Walls™ w/Smooth High-Gloss Exterior Tuff-Coat™ Fiberglass
- Vacu-Bond™ Upper/Lower Floors
| 34H | 38L | 38N | 38S | 38V | |
| Wheelbase (inches) | 208" | 252" | 252" | 252" | 252" |
| GVWR (lbs) | 31,000 | 31,000 | 31,000 | 31,000 | 31,000 |
| Front GAWR (lbs) | 12,000 | 12,000 | 12,000 | 12,000 | 12,000 |
| Rear GAWR (lbs) | 19,000 | 19,000 | 19,000 | 19,000 | 19,000 |
| Base Weight (lbs) | 22,155 | 24,000 | 22,324 | 22,605 | 24,000 |
| GCWR (lbs) | 41,000 | 41,000 | 41,000 | 41,000 | 41,000 |
| Tongue Weight (lbs) | 1,000 | 1,000 | 1,000 | 1,000 | 1,000 |
| Engine Displacement (Lit... | 7.2 | 7.2 | 7.2 | 7.2 | 7.2 |
| Hitch Rating Weight (lbs... | 10,000 | 10,000 | 10,000 | 10,000 | 10,000 |
| Engine | Cat® C7 300HP | Cat® C7 300HP | Cat® C7 300HP | Cat® C7 300HP | Cat® C7 300HP |
| Torque | 860 lb-ft @ 1440 RPM | 860 lb-ft @ 1440 RPM | 860 lb-ft @ 1440 RPM | 860 lb-ft @ 1440 RPM | 860 lb-ft @ 1440 RPM |
| Transmission | Allison® 3000MH 6-Speed w/Electronic Shifter | Allison® 3000MH 6-Speed w/Electronic Shifter | Allison® 3000MH 6-Speed w/Electronic Shifter | Allison® 3000MH 6-Speed w/Electronic Shifter | Allison® 3000MH 6-Speed w/Electronic Shifter |
| Alternator Amps | 170 Amp Leece Neville® | 170 Amp Leece Neville® | 170 Amp Leece Neville® | 170 Amp Leece Neville® | 170 Amp Leece Neville® |
| Overall Length | 34' 8" | 38' 4" | 38' 4" | 38' 4" | 38' 4" |
| Overall Height (with A/C... | 12' 10" | 12' 10" | 12' 10" | 12' 10" | 12' 10" |
| Overall Width (maximum) | 102" | 102" | 102" | 102" | 102" |
| Interior Height (maximum... | 84" | 84" | 84" | 84" | 84" |
| Interior Width (maximum) | 96" | 96" | 96" | 96" | 96" |
| Fresh Water Holding Tank... | 86 | 86 | 86 | 86 | 86 |
| Grey Water Holding Tank ... | 50 | 50 | 50 | 50 | 50 |
| Black Water Holding Tank... | 50 | 50 | 50 | 50 | 50 |
| Appliance Propane Tank (... | 25 | 25 | 25 | 25 | 25 |
| Water Heater Tank (gal) | 10 | 10 | 10 | 10 | 10 |
| Fuel Capacity (gal) | 90 | 90 | 90 | 90 | 90 |
