2006 Dutchmen T@B Fiberglass Specs, Towing Weight, Floorplan + Features
Photo Tour
Available Photos (Click to enlarge)
|
RV Must-Have! Never Run Out of Power Again!
|
Year: | 2006 |
---|---|
Manufacturer: | Dutchmen |
Model: | T@B Fiberglass |
RV Type: | Travel Trailer |
Condition: | New |
Price Range: | $9,000 - $17,000 |
Description
From the ground up, you'll find that T@B's revolutionary design has created an entirely new class of recreational vehicles in America.
T@B is a fully laminated travel trailer. Aluminum, AluFiber or Fiberglass skin is laminated over foam insulation. The double pane, tinted, poly plastic windows are top hinged for venting and feature rollaway screens and privacy shades. Choose from Jolt Grey, Orange Krush, Mellow Yellow, or Cherry Red exterior trim colors to personalize your new T@B. (Fiberglass model only available with Grey trim).
T@B features an Al-KO Kober ultra light frame. The galvanized frame features rubber torsion, independent suspension axles. Plus, the frame includes a surge brake coupler, parking brake, easy-up tongue jack, and four corner stabilizer jacks. T@B Aluminum is also available with performance low-profile, speed rated automotive tires and sporty aluminum rims.
Standing at an exterior height of 7' 7", T@B can be stored in most garages. Plus, the interior height of the trailer is an amazing 5' 9" making it the tallest ceiling height for tear drop trailers in America.
T@B is a fully laminated travel trailer. Aluminum, AluFiber or Fiberglass skin is laminated over foam insulation. The double pane, tinted, poly plastic windows are top hinged for venting and feature rollaway screens and privacy shades. Choose from Jolt Grey, Orange Krush, Mellow Yellow, or Cherry Red exterior trim colors to personalize your new T@B. (Fiberglass model only available with Grey trim).
T@B features an Al-KO Kober ultra light frame. The galvanized frame features rubber torsion, independent suspension axles. Plus, the frame includes a surge brake coupler, parking brake, easy-up tongue jack, and four corner stabilizer jacks. T@B Aluminum is also available with performance low-profile, speed rated automotive tires and sporty aluminum rims.
Standing at an exterior height of 7' 7", T@B can be stored in most garages. Plus, the interior height of the trailer is an amazing 5' 9" making it the tallest ceiling height for tear drop trailers in America.
Features
STANDARD FEATURES
- Exterior Laminated Filon fiberglass finish
- Fully laminated body w/ foam block insulation
- Available with Grey trim only
- 15" tire on steel rim
- Alko galvanized microlite frame
- Independent suspension frame
- Surge brakes/parking brake/tire jack
- 7-way plug/5,000# safety chains
- Two sets stabilizer jacks
- Four grab handles
- Custom taillights
- Same great floorplans
- Sink & stove top
- Two Poly Plastic, duo pane bay windows with roll-away screens/ shades
- Large dinette with storage
- Roof vent
- One Poly Plastic port-hole windows w/ shades (all floor plans)
- Manual water pump with 5 Gallon fresh water tank
- Exterior trim color available in one color: White with lower grey trim pieces and decal package
- Two interior fabric choices: Chicklet Blue and Starburst Green
- Awning and tent - N/A on fiberglass model
- "Easy-up" indoor/outdoor table
- Spare tire optional
- LP cover optional
Orginal Floorplan | Aluminum | Fiberglass | Alufiber |
Unloaded Vehicle Weight | 1346 | 1346 | 1346 |
GVWR | 1939 | 1939 | 1939 |
Carry Capacity | 593 | 593 | 593 |
Hitch Weight | 136 | 136 | 136 |
Exterior Length | 15'6" | 15'6" | 15'6" |
Exterior Width | 6'7" | 6'7" | 6'7" |
Exterior Height | 7'9" | 7'9" | 7'9" |
Interior Length | 10'3" | 10'3" | 10'3" |
Interior Height | 5'9" | 5'9" | 5'9" |
Fresh Water Capacity (ga... | 5 | 5 | 5 |
Lp Capacity (lbs) | 20 | 20 | 20 |
L Shapped Floorplan | Aluminum | Fiberglass | Alufiber |
Unloaded Vehicle Weight | 1453 | 1453 | 1453 |
GVWR | 1939 | 1939 | 1939 |
Carry Capacity | 483 | 483 | 483 |
Hitch Weight | 134 | 134 | 134/td> |
Exterior Length | 15'6" | 15'6" | 15'6" |
Exterior Width | 6'7" | 6'7" | 6'7" |
Exterior Height | 7'9" | 7'9" | 7'9" |
Interior Length | 10'3" | 10'3" | 10'3" |
Interior Height | 5'9" | 5'9" | 5'9" |
Fresh Water Capacity (ga... | 5 | 5 | 5 |
Lp Capacity (lbs) | 20 | 20 | 20 |
Clam Shell Floorplan | Aluminum | Alufiber |
Unloaded Vehicle Weight | 1409 | 1409 |
GVWR | 1939 | 1939 |
Carry Capacity | 530 | 530 |
Hitch Weight | 130 | 130 |
Exterior Length | 15'6" | 15'6" |
Exterior Width | 6'7" | 6'7" |
Exterior Height | 7'9" | 7'9" |
Interior Length | 10'3" | 10'3" |
Interior Height | 5'9" | 5'9" |
Fresh Water Capacity (ga... | 5 | 5 |
Lp Capacity (lbs) | 20 | 20 |
