2006 Dutchmen Aerolite Cub Specs, Towing Weight, Floorplan + Features

Photo Tour
zoom
Exterior
Available Photos (Click to enlarge)

RV Must-Have! Never Run Out of Power Again!
Year: 2006
Manufacturer: Dutchmen
Model: Aerolite Cub
RV Type: Travel Trailer
Condition: New
Price Range: $15,000 - $27,000
Description
EXPANDABLE COMFORT
For active families on the go, Cub expandable travel trailers add sleeping space without the additional length and weight that come with traditional travel trailers. And the lightweight design and aerodynamic profile make the Cub easy to tow.
From the ground up it’s easy to see that Cub offers the most value for your dollar. The fully laminated all aluminum super structure rests on a European style ultra lightweight frame. Fiberglass exterior walls and rubber lined roof are designed for years of enjoyable use. The expandable beds feature CAVLAR 2000 tents that include a full 5-year warranty. The Cub rides on Al-Ko rubber torsion axles that give it an “Independent Suspension” style ride. You won’t find all these features on the competition.
The interior of the Cub is our best looking ever. The designer décors with luxurious fabrics, raised panel upper cabinet doors, and Congoleum vinyl flooring make the Cub your best choice when it comes to expandable travel trailers. But the value doesn’t stop there. The kitchen in the Cub is loaded with features including a Norcold refrigerator, a 3-burner LP range, a double bowl composite sink with a high-rise faucet, and abundant storage. So if you are looking for the best built, feature-packed lightweight expandable, look no further.
Choose Cub from Aerolite. The original ultra-light travel trailer.
Features
OPTIONAL - CUB PACK GROUP:
  • 13.5 BTU air conditioning with wall thermostat
  • AM/FM/CD player with two speakers
  • A&E 8300 series awning
  • TV antenna with cable prep
  • Microwave
  • Bunk end lights with fan
  • Oven with three burner range
OTHER OPTIONAL FEATURES
  • Exterior sound system
  • Audiovox 2-way radio system: four 5-mile
  • Heated bunk mattress
  • Custom bike rack with truck receiver
  • Spare tire with cover
  • DSI water heater (gas/electric)
  • Hot/Cold Exterior shower
  • Stove cover
  • Water filter system
  • Exterior barbeque grill
  • Bi-fold shower door
  • Diamond plate lower front wall
  • Pac-n-play
  • 6 Cubic ft. Norcold double door gas/electric refrigerator
STANDARD - EXTERIOR FEATURES
  • 8' Wide floorplans
  • 2-20 lb LP bottles with ABS cover
  • Key-locking ?Easy Latch? tent doors
  • Self-Supporting bunk ends ? no poles required
  • 60" x 80" queen beds in tents
  • 26" radius corner entry door
  • Flush combo entry latch/deadbolt lock
  • ABS wheel wells
  • Tandem axles with 4-wheel electric brakes
  • 6-Way welded aluminum laminated superstructure (roof, floor and walls)
  • Lite-weight European-style frame with lifetime rust through warranty
  • ABS fender skirts
  • EPDM one-piece seamless rubber roof
  • Corrosion free laminated underbelly
  • High-end designer graphics
  • Rain gutter with corner downspouts
  • Rear bumper and corner guards
  • Single entry step
  • Tinted radius clamp ring windows
  • Exterior step light with switch
  • Entry-assist handle at door
  • Break-away trailer switch
  • 120V Exterior outlet
  • Safety glass
  • Four corner stabilizer jacks with sand pads
STANDARD - INTERIOR FEATURES
  • 5" Thick, reversible dinette seats
  • Bathroom medicine cabinet
  • Designer window treatments
  • Fiberlink bathtub
  • Shower curtain
  • Glass d?cor light over dinette table
  • Mini blinds throughout
  • Power roof vent in bathroom
  • Residential tile-like linoleum
STANDARD - APPLIANCES AND ELECTRICAL
  • 12V Electric slide-out motor
  • 19M BTU forced air DSI furnace
  • Ducted heat
  • 30 Amp power cord with storage compartment
  • 6 Gallon gas water heater with bypass
  • 12V interior lights with wall switch
  • Fire extinguisher
  • LP detector
  • Carbon monoxide detector
  • Smoke detector
  • Norcold single door gas/electric refrigerator
  • Pre-wired for air conditioning
  • Pre-wired for cable TV and stereo
  • Range hood with 12V light and exhaust fan
  • Solid state converter with built-in
  • battery charger
  • Systems monitor panel
  • Demand water pump
Floorplans 160 17FL 195 214 215 235 236 23BH 23TT
Axle Weight 2418 2286 2899 3297 3001 3269 3413 3401 3497
Dry Hitch Weight 305 321 231 351 299 345 315 461 513
Unloaded Vehicle Weight 2704 2608 3130 3648 3300 3614 3728 3862 4110
GVWR 3850 3850 4840 4840 4840 4840 4840 4840 6000
Net Cargo Capacity 1126 1242 1710 1192 1540 1226 1112 978 1890
Exterior Length (closed) 17’2” 17’5” 20’8” 24’4” 22’8” 24’4” 24’4” 26’4” 26’4”
Exterior Height with A/C 9’4” 9’4” 9’4” 9’4” 9’4” 9’4” 9’4” 9’4” 9’4”
Exterior Width 8’ 8’ 8’ 8’ 8’ 8’ 8’ 8’ 8’
Fresh Water Capacity 46 46 46 46 46 46 46 46 46
Gray Water Capacity 34 34 34 34 34 34 34 34 34
Black Water Capacity 22 22 22 22 22 32 22 22 22
Furnace Size (BTUs) 19,000 19,000 19,000 19,000 19,000 19,000 19,000 19,000 19,000
Floorplans (Click to enlarge)
160
160
195
195
214
214
215
215
235
235
236
236
